Band Knife Cutting Machine

  • Product Name:  Band Knife Cutting Machine
  • Model NO.:  KT-700-900-1200
  • Origin:  CHINA
  • Packing:  WOODEN CASE
  • Brand Name:  KUTEX
  • Delivery Time:  7DAYS
  • Minimum Order:  1 PC
  • Quality System Certification:  CE
  • Product Details:  Band Knife Cutting Machine

Band Knife Cutting Machine



1.Regulative cutting speed, the user can adjust various cutting speeds according to different fabrics. cloth cutter, strap knife cutter
2.It is attached with a special air-floated blowing device to reduce the excess resistance formed between the cutting sheet weight and cutting table. It makes more mobile for cutting sheet and more precise cutting for small cutting sheets.
3.An additional material is matched to keep the cutter under certain temperatures. The roller uses anti-Wear rubber to easily fix the cutter with no snake-like deviation. In this way, it prolongs the cutter life.
4.Extremely easy cut removal which is fit for any ordinary person.
5.It is attached with a grinding device to ensure constant sharp of the cutter. Cloth cutter, strap knife cutter
The main performances & parameters



Model KT700 KT900 KT1200
Table Size 1200*1800mm 1500*2100mm 1500*2400mm
Table Height  800-850mm 1500*2100mm 1500*2400mm
Max. Cutting thickness  180mm 200mm 250mm
Max. Cutting span  700mm 900mm 1200mm
Speed Control  Variable Speed Control 10-15m/s  Variable Speed Control 10-15m/s  Variable Speed Control 10-15m/s
Strap Specification
(L*W*T)
3590*10*0.45
mm
4005*10*0.45
mm
4560*10*0.45
mm
Power Supply  Three-Phase Three-Phase Three-Phase
Weight 265kg 285kg 340kg
Packing Size  1930*830*1830
mm
1980*880*1860
mm
2500*880*1860
mm
